Name: Connecting Rod Can-am, Bronco SM-09341 420-2174-25, 420-2174-29, 330-850cc 420233980, 420217429, 420217425
Brand: Namura Technologies
SKU: 56-9045.BR
Price: 114.7 GBP
Availability: InStock

Connecting Rod Can-am, Bronco SM-09341 420-2174-25, 420-2174-29, 330-850cc 420233980, 420217429, 420217425

Namura Technologies
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

The 56-9045.BR is a connecting rod assembly manufactured by Namura Technologies, offered as a heavy-duty OE replacement for various Can Am ATV and UTV models. It is sold complete with the rod, crankpin, crankpin bearing, top end bearing, and thrust washers, and is designed to provide robust performance for a wide range of applications.

Features

Heavy-duty OE replacement connecting rod
Certified chrome alloy steel for superior strength
Crankpins fabricated from hot-rolled ASTM steel and case hardened
Incorporates caged needle roller bearing design for high rpm longevity
Thrust washers constructed from phosphor bronze, silver coated
Rod assembly includes rod, crankpin, crankpin bearing, top end bearing and thrust washers
Fully compatible with aftermarket and OE crankshafts

Specifications

Material: SNCM220
Centre-to-centre length: 117mm
Small end bore diameter: 20mm
Small end width: 20mm
Big end bore diameter: 43mm
Big end width: 20mm
Weight: 0.522kg

Cross-Reference OEM Part Numbers

420-2174-25
420-2174-29
420-2339-80
420217429
420217425

Vehicle Fitments

Can Am Outlander 330 (2004-05)
Can Am Outlander 400 (2003-14)
Can Am Outlander 400 (International) (2015)
Can Am Outlander 450 (2015-18)
Can Am Outlander 650 (2006-18)
Can Am Outlander 800 (2006-15)
Can Am Renegade 800 (2007-15)
Can Am Outlander 850 (2016-18)
Can Am Renegade 850 (2016-18)
Can Am Defender HD5 427 (2017-18)
Can Am Traxter HD5 (2017-18)
Can Am Commander 800 (2011-18)
Can Am Defender HD8 800 (2016-18)
Can Am Traxter HD8 800 (2016-18)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
CAN-AM	OUTLANDER 330	2004-2005
CAN-AM	COMMANDER 800	2011-2018
CAN-AM	RENEGADE 800	2007-2015
CAN-AM	OUTLANDER 400	2015
CAN-AM	RENEGADE 850	2016-2019
CAN-AM	DEFENDER TRAXTER 800	2016-2019
CAN-AM	OUTLANDER 800	2006-2015
CAN-AM	OUTLANDER 400	2003-2014
CAN-AM	OUTLANDER 450	2015-2019
CAN-AM	OUTLANDER 650	2006-2019
CAN-AM	OUTLANDER 850	2016-2019
CAN-AM	DEFENDER TRAXTER 427	2017-2019

Connecting Rod Can-am, Bronco SM-09341 420-2174-25, 420-2174-29, 330-850cc 420233980, 420217429, 420217425

Namura Technologies
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

The 56-9045.BR is a connecting rod assembly manufactured by Namura Technologies, offered as a heavy-duty OE replacement for various Can... Read more

2 in stock 1-2 business days

£114.70 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-9045.BR

Free shipping on all orders above £75

No hassle returns within 30 days

Description

The 56-9045.BR is a connecting rod assembly manufactured by Namura Technologies, offered as a heavy-duty OE replacement for various Can Am ATV and UTV models. It is sold complete with the rod, crankpin, crankpin bearing, top end bearing, and thrust washers, and is designed to provide robust performance for a wide range of applications.

Features

Heavy-duty OE replacement connecting rod
Certified chrome alloy steel for superior strength
Crankpins fabricated from hot-rolled ASTM steel and case hardened
Incorporates caged needle roller bearing design for high rpm longevity
Thrust washers constructed from phosphor bronze, silver coated
Rod assembly includes rod, crankpin, crankpin bearing, top end bearing and thrust washers
Fully compatible with aftermarket and OE crankshafts

Specifications

Material: SNCM220
Centre-to-centre length: 117mm
Small end bore diameter: 20mm
Small end width: 20mm
Big end bore diameter: 43mm
Big end width: 20mm
Weight: 0.522kg

Cross-Reference OEM Part Numbers

420-2174-25
420-2174-29
420-2339-80
420217429
420217425

Vehicle Fitments

Can Am Outlander 330 (2004-05)
Can Am Outlander 400 (2003-14)
Can Am Outlander 400 (International) (2015)
Can Am Outlander 450 (2015-18)
Can Am Outlander 650 (2006-18)
Can Am Outlander 800 (2006-15)
Can Am Renegade 800 (2007-15)
Can Am Outlander 850 (2016-18)
Can Am Renegade 850 (2016-18)
Can Am Defender HD5 427 (2017-18)
Can Am Traxter HD5 (2017-18)
Can Am Commander 800 (2011-18)
Can Am Defender HD8 800 (2016-18)
Can Am Traxter HD8 800 (2016-18)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
CAN-AM	OUTLANDER 330	2004-2005
CAN-AM	COMMANDER 800	2011-2018
CAN-AM	RENEGADE 800	2007-2015
CAN-AM	OUTLANDER 400	2015
CAN-AM	RENEGADE 850	2016-2019
CAN-AM	DEFENDER TRAXTER 800	2016-2019
CAN-AM	OUTLANDER 800	2006-2015
CAN-AM	OUTLANDER 400	2003-2014
CAN-AM	OUTLANDER 450	2015-2019
CAN-AM	OUTLANDER 650	2006-2019
CAN-AM	OUTLANDER 850	2016-2019
CAN-AM	DEFENDER TRAXTER 427	2017-2019
