Description

Connecting rod rebuild kit for Suzuki RM125 (1988–1996), engineered as a heavy-duty OE replacement. Built using certified chrome alloy steel for enhanced durability and longevity, this complete assembly is compatible with both aftermarket and OE crankshafts.

Features

Heavy-duty connecting rod designed as an OE replacement.
Constructed from certified chrome alloy steel for superior strength.
Crankpins are hot-rolled ASTM steel and case-hardened for durability.
Utilizes advanced caged needle roller bearing designs for high rpm performance.
Thrust washers made from bronze phosphor with a silver coating.
Complete assembly includes rod, crankpin, crankpin bearing, top-end bearing, and thrust washers if required.
Fully compatible with aftermarket and OE crankshafts.

Specifications

Material: SNCM220
Centre-to-Centre: 105 mm
Small End Bearing: 15x19x19.80 mm
Small End Bore Ø: 19 mm
Small End Width: 18 mm
Big End Bearing: 22x28x15.8 mm
Big End Bore Ø: 28 mm
Big End Width: 16 mm
Big End Pin Ø: 22 mm
Big End Pin Length: 53 mm
Washer Thickness: 1.0 mm

Cross Reference OEM Part Numbers

Suzuki: 12161-01B41
Suzuki: 12161-27C00-0B0
Suzuki: 12161-27C00-0D0
Suzuki: 12161-27C10
Suzuki: 12161-43D00
Hotrods 8110
ProX 03-3207
Wossner P2015

Vehicle Fitments

Suzuki RM125: 1988–1996

Part Number: 56-924.DR

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
SUZUKI	RM 125	1987
SUZUKI	RM 125	1988-1996
SUZUKI	RM 125	1987-1996
