Connecting Rod KTM 250 300, Psychic MX-09099

Description

High-quality connecting rod rebuild kit designed for KTM two-stroke models. Manufactured using hot-rolled ASTM and case-hardened materials, this kit ensures durability and precision. The double-forged rods enhance grain flow and maintain consistent dimensions, while shot-peening and double-honing processes provide superior strength under heavy loads. The small end features double-drilled holes for enhanced lubrication and cooling, crucial for high-performance applications. Thrust washers and crank pin bearings are silver-coated for added lubricity. The kit includes all necessary components for a complete rebuild: rod, crank pin, crank pin bearing, top-end bearing, and thrust washers.

Features:

  • Hot-rolled ASTM and case-hardened materials for enhanced durability.
  • Double-forged rods for improved grain flow and dimensional consistency.
  • Shot-peened and double-honed rods for increased strength under load.
  • Double-drilled small end for superior lubrication and cooling.
  • Silver-coated thrust washers and crank pin bearings for added lubricity.
  • Complete kit includes rod, crank pin, crank pin bearing, top-end bearing, and thrust washers.

Specifications:

  • Centre-to-Centre Distance: 132 mm
  • Small End Bearing Dimensions: 18x22x19.8 mm
  • Small End Bore Ø: 22 mm
  • Small End Width: 17.00 mm
  • Big End Bearing Dimensions: 24x30x16.8 mm
  • Big End Bore Ø: 30 mm
  • Big End Width: 16.90 mm
  • Big End Pin Ø: 24 mm
  • Big End Pin Length: 59.90 mm
  • Washer Thickness: 1.00 mm

Cross-Reference OEM Part Numbers:

54630015044, HOTRODS 8111, PROX 03.6311, WOSSNER P2024

Vehicle Compatibility:

KTM Models (1990–2003):
250 SX-EXC, 300 SX-EXC, 360/380cc

  • 1990–1999: 250 EXC, 250 SX, 250 XC, 250 XC-W
  • 1990–2003: 300 EXC, 300 MXC, 300 XC, 300 XC-W

Part Number: 56-894.DR

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer Model Years
KTM SX 300 1990-2003
KTM EXC 300 1990-2003
KTM XC 250 1990-1999
KTM SX 250 1990-1999
KTM EXC 250 1990-1999
KTM XCR W 250 1990-1999
KTM XCF W 250 1990-1999
KTM XCF 250 1990-1999
KTM XC WE 250 1990-1999
KTM XC W E 250 1990-1999
KTM XC W 250 1990-1999
KTM XC W 300 1990-1999
KTM XC FW 250 1990-1999
KTM XC F 250 1990-1999
KTM XC F 300 1990-1999
KTM XC 300 1990-1999
KTM SXS 250 1990-1999
KTM SX 300 1990-1999
KTM MXC 250 1990-1999
KTM MXC 300 1990-1999
KTM MX 250 1990-1999
KTM MX 300 1990-1999
KTM GS 250 1990-1999
KTM GS 300 1990-1999
KTM FREERIDE 250 1990-1999
KTM EXC R 250 1990-1999
KTM EXC G 250 1990-1999
KTM EXC F 250 1990-1999
KTM EXC E 300 1990-1999
KTM EXC 300 1990-1999
KTM EGS 250 1990-1999
KTM EGS 300 1990-1999
KTM CROSS 250 1990-1999
