Description
CONNECTING CONROD ROD REBUILD KIT BRONCO AT-09171
SUZUKI
2013 LT-F250 KINGQUAD,
1988-02 LT-F250 QUAD RUNNER,
2002-14 LT-F250 OZARK,
1999-02 LT-F250F QUAD RUNNER 4X4,
2004-09 LT-Z250 QUADSPORT,
- Heavy-duty OE replacement connecting rods.
- Certified Chorme alloy steel provides superior strength.
- Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
- BRONCO Rods uses the latest in caged needle roller bearing designs for high rpm longevity.
- Thrust washers are manufactured from bronze phosphor and are silver coated.
- Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
- Fully Compatible with after market and OE crankshafts.
- Material SNCM220,
- Please see image before ordering to avoid mistakes.
- BRONCO products are a high quality replacement part and
| SIZE | MM |
| Centre 2 Centre | 115.50 |
| Small End Bearing | None |
| Small End Bore Ø | 16 |
| Small End Width | 14
|
| Big End Bearing | 30x39x18 |
| Big End Bore Ø | 39 |
| Big End Width | 18
|
| Big End Pin Ø | 30 |
| Big End Pin Length | 53.00
|
| Washer Thickness |
None
|
Part No. 56-251.DR (radhouse.co.uk)
Cross reference numbers ONLY.
VA-3005,
ROD, CONNECTING 12161-19B02, 12161-19B03
PIN, CRANK MODEL X/Y 12210-22A02, 12210-22A03
PIN, CRANK MODEL K1/K2 12210-22A03
BEARING (30X39X18) 09263-30033-0B0
Vehicle Compatibility
Please check the exact model and year before ordering.
| Manufacturer |
Model |
Years |
| SUZUKI |
LT F QUADRUNNER 250 |
1999-2002 |
| SUZUKI |
LT EF 250 |
1985-1986 |
| SUZUKI |
LT F QUADRUNNER 250 |
1988-2002 |
| SUZUKI |
LT F OZARK 250 |
2002-2014 |
| SUZUKI |
LT F QUADRUNNER 250 |
1988-2001 |
| SUZUKI |
LT F OZARK 250 |
2002-2006 |
| SUZUKI |
LTZ 250 |
2004-2009 |
| SUZUKI |
LT F 250 |
2013 |
| SUZUKI |
LT 250 |
1987-1998 |
