HD RECTIFIER SUZUKI YAMAHA FIR BRAND 32800-19063 Heavy duty

Description

The FIR heavy-duty two-wire rectifier is a replacement diode unit for the electrical systems of the listed Suzuki and Yamaha models. It rectifies alternating current for use in the charging circuit and is supplied with mounting hardware. Check the wire colours, dimensions and mounting hole against the part being replaced, as the listed fitments span several types of motorcycle and equipment.

Features

  • Two-wire connection for rectifier replacement.
  • Supplied with a bolt, nut and washer for mounting.

Specifications

  • Body dimensions: 31 × 27 × 10 mm.
  • Wire colours: green and red.
  • Wire length: 15.5 cm.
  • Mounting hole diameter: 6.2 mm.
  • Material: aluminium.

Cross-Reference OEM Part Numbers

  • FIR: 44-600S.
  • Suzuki: 32800-02110, 32800-02111, 32800-16A00, 32800-19063.
  • Yamaha: 353-81970-50, 353-81970-60, 353-81970-63, 353-81970-M0.
  • Other cross-reference numbers: 3150-1, 563235, 715000.

Vehicle Fitments

  • Suzuki A100: 1988–1992; A100 A (1976), B (1977–1978), K (1973), L (1974), M (1975) and N (1979); 100 cc.
  • Suzuki A50: 1969–1979; 50 cc.
  • Suzuki AP50: 1975–1978; 50 cc.
  • Suzuki CL50D: 1983; CL50 DD Love: 1983–1984; 50 cc.
  • Suzuki CS50 Gemma Quest: 1982–1983; CS50 Z Roadie: 1982; CS50 D Roadie: 1983–1984; 50 cc.
  • Suzuki DR400 ST: 1980; DR400 SX: 1981; 400 cc.
  • Suzuki DR500 SD: 1983; DR500 SE: 1984.
  • Suzuki F50: 1971–1973; 50 cc.
  • Suzuki FA50: 1988–1991.
  • Suzuki FM50 AH: 1987; AM: 1991; AR: 1994.
  • Suzuki FR50: 1974–1981; FR50 X: 1999; 50 cc for 1974–1981 models.
  • Suzuki FR70: 1974–1976; 70 cc.
  • Suzuki FR80 B: 1977–1978; D: 1983; M: 1975–1976; N: 1979–1980; X: 1981; Z: 1982; 80 cc.
  • Suzuki FS50 T Snip: 1980; FS50 X Snip: 1981; 50 cc.
  • Suzuki FZ50 N Suzy: 1979–1980; X Suzy: 1981; Z Suzy: 1982; FZ50 G: 1986; FZ50 K: 1989; 50 cc for 1979–1982 models.
  • Suzuki GN400 TT: 1980; 400 cc.
  • Suzuki GP100 C: 1978; D and ED: 1983–1987; N: 1979–1980; UC: 1978; UD: 1983–1989; UL: 1990–1992; UN: 1979–1980; UX and X: 1981–1982; 100 cc.
  • Suzuki GP125 C: 1978; D: 1983–1984; N: 1979–1980; X: 1981–1982; UC: 1978; UN: 1992; UX: 1999; 125 cc for C, D, N and X models.
  • Suzuki GT185 A: 1976; B: 1977; C and EC: 1978; K: 1973; L: 1974; M: 1975; 185 cc.
  • Suzuki OR50: 1979–1980; 50 cc.
  • Suzuki PE400 T: 1980; X: 1981; 400 cc.
  • Suzuki PV50 D: 1983; H: 1987; L: 1990; M: 1991; R: 1994; X: 1999.
  • Suzuki RV50: 1983 and 1999.
  • Suzuki RV125 A: 1976; K: 1973; L: 1974; M: 1975; 125 cc.
  • Suzuki SP370 C: 1978; N: 1979; 370 cc.
  • Suzuki SP400 T: 1980; 400 cc.
  • Suzuki TF125: 1998–1999 and 2005.
  • Suzuki TS50 ER: 1982–1996 and 1999; ERKD: 1983; ERKT: 1980; ERKX: 1981; ERKZ: 1982; KC: 1978; KN: 1979; 50 cc for the specified ERK, KC and KN models.
  • Suzuki TS100 A: 1976; B: 1977; C: 1978; ERN: 1979; ERT: 1980; ERX: 1981; K: 1973; L: 1974; M: 1975; 100 cc.
  • Suzuki TS125 A: 1976; B: 1977; C: 1978; ERN and N: 1979; ERT: 1980; ERX: 1981; K: 1973; L: 1974; M: 1975; 125 cc.
  • Suzuki TS185 A: 1976; B: 1977; C: 1978; ERN: 1979; K: 1973; L: 1974; M: 1975; 185 cc. TS185 ER is also listed for 1982–1992 and 1994.
  • Suzuki TS250 A: 1976; B: 1977; C: 1978; ERN: 1979; ERT: 1980; ERX: 1981; K: 1973; L: 1974; M: 1975; 250 cc. TS250 ER is also listed for 1992–1996 and 1999.
  • Suzuki ZR50 KEN ‘X1’: 1979–1981; KEX ‘X1’: 1981; SKE: 1984–1986; SKH: 1987; SKX: 1982–1983; SLKX: 1981; 50 cc.
  • Yamaha AG100 H: 1996.
  • Yamaha DT50LC: 1991–1993; DT50MX: 1986–1992.
  • Yamaha DT80: 1981–1983 and 1987; DT100: 1974–1983; DT175: 1974–1976; DT250 A: 1974; DT360 A: 1974.
  • Yamaha FS1 50: 1977–1978 and 1987–1989.
  • Yamaha GT1 100: 1973; GT80: 1974–1980; GTMX: 1973–1976.
  • Yamaha IT200: 1986.
  • Yamaha LB50: 1978–1982 and 1988–1990; LB80: 1976–1981; LB80 2: 1976–1978.
  • Yamaha LC50 G: 1980; MJ50 J: 1982; MR50: 1980; QT50: 1979–1987.
  • Yamaha RD50: 1979 and 1986; RD60: 1973–1975; RD80: 1982.
  • Yamaha RS100: 1975–1976; RX50: 1982–1984; RZ50: 1985.
  • Yamaha TT600 W: 1989.
  • Yamaha TY50 M: 1977–1978; TY125: 1989; TY250 S: 1984 and 1988.
  • Yamaha XT125: 1982–1991; XT200: 1982–1983; XT500: 1976–1981.
  • Yamaha YB100: 1987; YSR50: 1987; YSR80: 1986.

Equipment Fitments

  • Yamaha YS-624 snow blower: 1994 and 1996; YS-628 snow blower: 1994–1997.
  • Yamaha EF2800iSE generator: 2012 and 2015; EF2800ISE 7WL1: 2002; 7CH1: 2004; 7CHB: 2005–2006; 7CHL: 2012.
  • Yamaha EF3000iSE 7WL3 generator: 2002; 7CHD: 2005; EF3000ISEC 7CH3: 2004.
  • Yamaha EF2300SE 7TD1 generator: 1997–1998.
  • Yamaha EF3600 73K generator: 1984; EF4300 73A: 1984; EF4300T 73J: 1984.
