Name: Piston Kit 05-07 CR125 54.00 B, Wossner 8170DB Honda MX
Brand: Wossner
SKU: 56-W859.B.WO

Piston Kit 05-07 CR125 54.00 B, Wossner 8170DB Honda MX

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

This Wossner 8170DB piston kit with a 54.01mm bore (+0.01mm oversize) is designed for Honda CR125R models from 2005 to 2007. The forged construction ensures enhanced strength, superior heat dissipation, and optimised performance under high-stress two-stroke operating conditions.

Features

+0.01mm oversize forged piston for Honda CR125R engines
Engineered for efficient heat transfer from combustion chamber to cylinder wall
Elliptical profile provides consistent bearing surface during heat expansion
Prevents localised pressure and minimises risk of piston collapse
Manufactured in Germany

Specifications

Bore diameter: 54.01 mm
Display displacement: 125 cm³
Stroke: 54.50 mm
Clearance: 0.05 mm
Compression ratio: 2-stroke (Wossner and OEM specification)
Compression height: 28.00 mm

Cross-Reference OEM Part Numbers

13110-KSR-730
13120-KSR-730
13111-KV3-000
13111-KZ4-000
13121-KSR-731
94601-15000
Wossner 8170DA
Namura NX-10003
Wiseco 859M05400

Included Components

Piston kit part number: 56-W859.B.WO
Circlip: CW15
Wrist pin: WP032
Ring set: RSB5400
Connecting rod: P2009

Vehicle Fitments

2005 Honda CR125R
2006 Honda CR125R
2007 Honda CR125R

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
HONDA	CR 125	2005-2007
