Name: Piston Kit 08-12 WR250X 77.00, Comp. 13.5:1 Wossner 8729DB
Brand: Wossner
SKU: 56-W238+00B.WO
Price: 201.63 GBP
Availability: InStock

Piston Kit 08-12 WR250X 77.00, Comp. 13.5:1 Wossner 8729DB

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

Wossner forged piston kit with a 77.01mm bore and 76.97mm diameter, designed for Yamaha WR250X models. Manufactured in Germany, this piston offers superior strength and design, ensuring optimal heat transfer to cylinder walls. Its elliptical design provides a uniform bearing surface under heat expansion, reducing localized pressure and evenly distributing thrust loads to prevent piston collapse.

Features

Forged construction for superior strength
Optimized heat transfer for efficient combustion
Elliptical design for uniform load distribution
Manufactured in Germany

Specifications

Bore: 77.01mm
Diameter: 76.97mm
Display (cm³): 249
Stroke (mm): 53.60
Clearance (mm): 0.04
Wossner Compression Ratio: OEM
OEM Compression Ratio: 11.80:1
Dome Volume (cm³): -5.90
Compression Height (mm): 22.90

Cross-Reference OEM Part Numbers

Wossner Piston Yamaha WR250X (PN# 8729DB)
Lock P/N: CW17
Pin P/N: WP083
Ring Set P/N: 770XAS-2

Vehicle Fitments

Yamaha WR250X (2008-2009)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
YAMAHA	WR X 250	2008-2012

Piston Kit 08-12 WR250X 77.00, Comp. 13.5:1 Wossner 8729DB

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

Wossner forged piston kit with a 77.01mm bore and 76.97mm diameter, designed for Yamaha WR250X models. Manufactured in Germany, this... Read more

2 in stock 1-2 business days

£201.63 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W238+00B.WO

Free shipping on all orders above £75

No hassle returns within 30 days

Description

Wossner forged piston kit with a 77.01mm bore and 76.97mm diameter, designed for Yamaha WR250X models. Manufactured in Germany, this piston offers superior strength and design, ensuring optimal heat transfer to cylinder walls. Its elliptical design provides a uniform bearing surface under heat expansion, reducing localized pressure and evenly distributing thrust loads to prevent piston collapse.

Features

Forged construction for superior strength
Optimized heat transfer for efficient combustion
Elliptical design for uniform load distribution
Manufactured in Germany

Specifications

Bore: 77.01mm
Diameter: 76.97mm
Display (cm³): 249
Stroke (mm): 53.60
Clearance (mm): 0.04
Wossner Compression Ratio: OEM
OEM Compression Ratio: 11.80:1
Dome Volume (cm³): -5.90
Compression Height (mm): 22.90

Cross-Reference OEM Part Numbers

Wossner Piston Yamaha WR250X (PN# 8729DB)
Lock P/N: CW17
Pin P/N: WP083
Ring Set P/N: 770XAS-2

Vehicle Fitments

Yamaha WR250X (2008-2009)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
YAMAHA	WR X 250	2008-2012
