Name: Piston Kit 16-22 SXF250 78mm A, Wossner 8923DA KTM 79030207000
Brand: Wossner
SKU: 56-W265.A.WO
Price: 202.09 GBP
Availability: InStock

Piston Kit 16-22 SXF250 78mm A, Wossner 8923DA KTM 79030207000

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

Piston kit 78mm Bore 77.96 Wossner 8923DA (STD)

KTM
SX-F250 2016 -,2022

Wossner forged pistons are superior in strength and design.
Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
Made in Germany.

Part No. 56-W265.A.WO (radhouse.co.uk)
WOSSNER 8923DA PISTON KIT BORE 78.00
Stroke: 52.3
Comp. ratio: 13.9:1
Dome Volume (CC) -1.80 cm?
Comp. Height (mm) 19.5
Lock P/N CW16
Pin P/N WP070
Ring Set P/N RIK78.00

Display (cm3) 249
Hub stroke (mm) 52.30
Clearance (mm) 0.04
Wossner compression Ratio: OEM
OEM Compression ratio: 13.90:1
Dome volume (cm3) -1.80
Compression height (mm) 19.50
Theorectical weight (G) 135.00

Cross reference numbers ONLY.
79030207000, 40144M07800

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
KTM	EXC F 250	2017-2019
GAS-GAS	MC F 250	2021
GAS-GAS	EX F 250	2021
KTM	SX F 250	2016-2018
KTM	XC F 250	2016-2019
KTM	SX F 250	2016-2019
KTM	SX F 250	2016-2020
HUSQVARNA	FE 250	2017-2019
HUSQVARNA	FC 250	2016-2019
HUSQVARNA	FC 250	2016-2020
KTM	XC F 250	2016-2021
KTM	SX F 250	2016-2021
HUSQVARNA	FC 250	2016-2021
KTM	EXC F 250	2016-2017
HUSQVARNA	FE 250	2016
KTM	SX F 250	2016
KTM	EXC F 250	2016-2018

Piston Kit 16-22 SXF250 78mm A, Wossner 8923DA KTM 79030207000

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

Piston kit 78mm Bore 77.96 Wossner 8923DA (STD) KTM SX-F250 2016 -,2022 Wossner forged pistons are superior in strength and... Read more

3 in stock 1-2 business days

£202.09 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W265.A.WO

Free shipping on all orders above £75

No hassle returns within 30 days

Description

Piston kit 78mm Bore 77.96 Wossner 8923DA (STD)

KTM
SX-F250 2016 -,2022

Wossner forged pistons are superior in strength and design.
Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
Made in Germany.

Part No. 56-W265.A.WO (radhouse.co.uk)
WOSSNER 8923DA PISTON KIT BORE 78.00
Stroke: 52.3
Comp. ratio: 13.9:1
Dome Volume (CC) -1.80 cm?
Comp. Height (mm) 19.5
Lock P/N CW16
Pin P/N WP070
Ring Set P/N RIK78.00

Display (cm3) 249
Hub stroke (mm) 52.30
Clearance (mm) 0.04
Wossner compression Ratio: OEM
OEM Compression ratio: 13.90:1
Dome volume (cm3) -1.80
Compression height (mm) 19.50
Theorectical weight (G) 135.00

Cross reference numbers ONLY.
79030207000, 40144M07800

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
KTM	EXC F 250	2017-2019
GAS-GAS	MC F 250	2021
GAS-GAS	EX F 250	2021
KTM	SX F 250	2016-2018
KTM	XC F 250	2016-2019
KTM	SX F 250	2016-2019
KTM	SX F 250	2016-2020
HUSQVARNA	FE 250	2017-2019
HUSQVARNA	FC 250	2016-2019
HUSQVARNA	FC 250	2016-2020
KTM	XC F 250	2016-2021
KTM	SX F 250	2016-2021
HUSQVARNA	FC 250	2016-2021
KTM	EXC F 250	2016-2017
HUSQVARNA	FE 250	2016
KTM	SX F 250	2016
KTM	EXC F 250	2016-2018
