Name: Piston Kit 1988 RM125 54.50, Wossner 8138D050 Suzuki MX 12110-14513
Brand: Wossner
SKU: 56-W568+050.WO

Piston Kit 1988 RM125 54.50, Wossner 8138D050 Suzuki MX 12110-14513

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

The Wossner 8138D050 piston kit is designed for the 1988 Suzuki RM125, featuring a 54.50 mm bore for +0.50 mm oversize applications. Precision-manufactured in Germany, this forged piston offers superior strength and efficient thermal transfer. Its elliptical design promotes even bearing surface contact under high-temperature expansion, minimising localised pressure and reducing the risk of piston collapse. This kit includes all necessary components for dependable engine rebuilding.

Features

Forged piston delivers high strength and thermal efficiency
Enhanced heat transfer from combustion chamber to cylinder walls
Elliptical profile ensures uniform pressure distribution under heat
Reduces the likelihood of piston collapse due to thermal stress
Made in Germany for precision and performance

Specifications

Bore Size: 54.50 mm
Actual Bore Diameter: 54.44 mm
Stroke: 54.00 mm
Display Displacement: 123 cm³
Clearance: 0.06 mm
Compression Ratio (Wossner and OEM): 2-stroke
Compression Height: 29.50 mm

Cross-Reference OEM Part Numbers

12110-14513

Cross-Reference Wossner Part Numbers

Piston Kit: 8138D050
Lock: CW15
Pin: WP032
Ring Set: RSB5450
Rod: P2015
Part No.: 56-W568+050.WO

Vehicle Fitments

Suzuki RM125 (1988)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
SUZUKI	RM 125	1988

Piston Kit 1988 RM125 54.50, Wossner 8138D050 Suzuki MX 12110-14513

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

The Wossner 8138D050 piston kit is designed for the 1988 Suzuki RM125, featuring a 54.50 mm bore for +0.50 mm... Read more

Out of stock

£0.00 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W568+050.WO

Free shipping on all orders above £75

No hassle returns within 30 days

Description

The Wossner 8138D050 piston kit is designed for the 1988 Suzuki RM125, featuring a 54.50 mm bore for +0.50 mm oversize applications. Precision-manufactured in Germany, this forged piston offers superior strength and efficient thermal transfer. Its elliptical design promotes even bearing surface contact under high-temperature expansion, minimising localised pressure and reducing the risk of piston collapse. This kit includes all necessary components for dependable engine rebuilding.

Features

Forged piston delivers high strength and thermal efficiency
Enhanced heat transfer from combustion chamber to cylinder walls
Elliptical profile ensures uniform pressure distribution under heat
Reduces the likelihood of piston collapse due to thermal stress
Made in Germany for precision and performance

Specifications

Bore Size: 54.50 mm
Actual Bore Diameter: 54.44 mm
Stroke: 54.00 mm
Display Displacement: 123 cm³
Clearance: 0.06 mm
Compression Ratio (Wossner and OEM): 2-stroke
Compression Height: 29.50 mm

Cross-Reference OEM Part Numbers

12110-14513

Cross-Reference Wossner Part Numbers

Piston Kit: 8138D050
Lock: CW15
Pin: WP032
Ring Set: RSB5450
Rod: P2015
Part No.: 56-W568+050.WO

Vehicle Fitments

Suzuki RM125 (1988)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
SUZUKI	RM 125	1988
