Piston Kit 2010 KX250F 77mm A, Wossner 8778DA Kawasaki Hc 13001-0115, Comp 13.9:1

Description

This Wossner forged high-compression piston kit features a 77mm bore size (76.96mm actual) and is designed for the 2010 Kawasaki KX250F. Manufactured in Germany, it includes a two-ring configuration and a high-compression dome for increased performance. The elliptical design ensures consistent load distribution, while efficient heat transfer supports durability under high-stress conditions.

Features

  • Forged high-compression piston with two-ring design

  • Elliptical profile ensures even thrust load distribution under heat expansion

  • Designed for optimal combustion heat transfer to cylinder walls

  • Manufactured in Germany

Specifications

  • Bore Size: 77mm (actual 76.96mm)

  • Displacement: 250 cm³

  • Stroke: 53.60 mm

  • Clearance: 0.04 mm

  • Compression Ratio (Wossner): 13.90:1

  • Compression Ratio (OEM): 13.20:1

  • Dome Volume: -1.40 cm³

  • Compression Height: 19.60 mm

  • Lock Part Number: CW16

  • Pin Part Number: WP070

  • Ring Set Part Number: 770XAS

Cross-Reference OEM Part Numbers

  • OEM: 13001-0115

  • Wiseco: 40009M

  • Vertex: 23566

  • ProX: 01.4340

  • Wiseco: 40010M07700

Vehicle Fitments

  • 2010 Kawasaki KX250F

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer Model Years
KAWASAKI KX F 250 2010

Piston Kit 2010 KX250F 77mm A, Wossner 8778DA Kawasaki Hc 13001-0115, Comp 13.9:1

Product form

This Wossner forged high-compression piston kit features a 77mm bore size (76.96mm actual) and is designed for the 2010 Kawasaki... Read more

2 in stock 1-2 business days

£202.09 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    SKU: 56-W953.A.WO.HC

    • Free shipping on all orders above £75
    • No hassle returns within 30 days

    Description

    This Wossner forged high-compression piston kit features a 77mm bore size (76.96mm actual) and is designed for the 2010 Kawasaki KX250F. Manufactured in Germany, it includes a two-ring configuration and a high-compression dome for increased performance. The elliptical design ensures consistent load distribution, while efficient heat transfer supports durability under high-stress conditions.

    Features

    • Forged high-compression piston with two-ring design

    • Elliptical profile ensures even thrust load distribution under heat expansion

    • Designed for optimal combustion heat transfer to cylinder walls

    • Manufactured in Germany

    Specifications

    • Bore Size: 77mm (actual 76.96mm)

    • Displacement: 250 cm³

    • Stroke: 53.60 mm

    • Clearance: 0.04 mm

    • Compression Ratio (Wossner): 13.90:1

    • Compression Ratio (OEM): 13.20:1

    • Dome Volume: -1.40 cm³

    • Compression Height: 19.60 mm

    • Lock Part Number: CW16

    • Pin Part Number: WP070

    • Ring Set Part Number: 770XAS

    Cross-Reference OEM Part Numbers

    • OEM: 13001-0115

    • Wiseco: 40009M

    • Vertex: 23566

    • ProX: 01.4340

    • Wiseco: 40010M07700

    Vehicle Fitments

    • 2010 Kawasaki KX250F

    Vehicle Compatibility

    Please check the exact model and year before ordering.

    Manufacturer Model Years
    KAWASAKI KX F 250 2010
