Name: Piston Kit 86-07 CR85 47.50, Wossner 8238D050 Honda MX
Brand: Wossner
SKU: 56-W643.P2A.WO

Piston Kit 86-07 CR85 47.50, Wossner 8238D050 Honda MX

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

The Wossner 8237D050 piston kit with a 47.5mm bore (46.95mm actual size) is crafted for Honda CR80 models from 1992 to 2002 (US Bore). This forged piston is produced in Germany and designed to improve heat transfer from the combustion chamber to the cylinder walls. Its elliptical profile ensures even load distribution during thermal expansion, minimising localised pressure and preventing piston collapse.

Features

Forged construction for enhanced strength and durability
Designed to optimise heat transfer to the cylinder walls
Elliptical design for uniform load distribution during heat expansion
Manufactured in Germany

Specifications

Bore: 47.5mm (actual size 46.95mm)
Part Number: 56-W643.P2A.WO
Lock Part Number: CW14
Pin Part Number: WP058
Ring Set Part Number: RSB4750
Displacement: 80 cm³
Stroke: 70.80mm
Clearance: 0.06mm
Wossner Compression Ratio: 2-stroke
OEM Compression Ratio: 2-stroke
Compression Height: 37.00mm

Cross-Reference OEM Part Numbers
(Cross-reference part numbers were not provided in your input for this piston. If available, they should be added here.)

Vehicle Fitments

1986 Honda CR80
1987 Honda CR80
1988 Honda CR80
1989 Honda CR80
1990 Honda CR80
1991 Honda CR80

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
HONDA	CR 85	2003-2007
HONDA	CR 80	1986-2002
HONDA	CR 80	1992-2002

Piston Kit 86-07 CR85 47.50, Wossner 8238D050 Honda MX

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

The Wossner 8237D050 piston kit with a 47.5mm bore (46.95mm actual size) is crafted for Honda CR80 models from 1992... Read more

Out of stock

£0.00 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W643.P2A.WO

Free shipping on all orders above £75

No hassle returns within 30 days

Description

The Wossner 8237D050 piston kit with a 47.5mm bore (46.95mm actual size) is crafted for Honda CR80 models from 1992 to 2002 (US Bore). This forged piston is produced in Germany and designed to improve heat transfer from the combustion chamber to the cylinder walls. Its elliptical profile ensures even load distribution during thermal expansion, minimising localised pressure and preventing piston collapse.

Features

Forged construction for enhanced strength and durability
Designed to optimise heat transfer to the cylinder walls
Elliptical design for uniform load distribution during heat expansion
Manufactured in Germany

Specifications

Bore: 47.5mm (actual size 46.95mm)
Part Number: 56-W643.P2A.WO
Lock Part Number: CW14
Pin Part Number: WP058
Ring Set Part Number: RSB4750
Displacement: 80 cm³
Stroke: 70.80mm
Clearance: 0.06mm
Wossner Compression Ratio: 2-stroke
OEM Compression Ratio: 2-stroke
Compression Height: 37.00mm

Cross-Reference OEM Part Numbers
(Cross-reference part numbers were not provided in your input for this piston. If available, they should be added here.)

Vehicle Fitments

1986 Honda CR80
1987 Honda CR80
1988 Honda CR80
1989 Honda CR80
1990 Honda CR80
1991 Honda CR80

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
HONDA	CR 85	2003-2007
HONDA	CR 80	1986-2002
HONDA	CR 80	1992-2002
