Name: Piston Kit 89-95 RM250 67.00 B, Wossner 8022DB Suzuki MX
Brand: Wossner
SKU: 56-W642.00B.WO

Piston Kit 89-95 RM250 67.00 B, Wossner 8022DB Suzuki MX

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

The Wossner 8022DB piston with a 67.01mm bore (66.95mm actual size) is engineered for high performance and durability, fitting Suzuki RM250 (1989-1995) and RMX250 (1993-1995) models. Forged in Germany, this piston is designed to optimise heat transfer from the combustion chamber to the cylinder walls. Its elliptical shape ensures uniform bearing surfaces during heat expansion, preventing localised pressure and piston collapse.

Features

Forged construction for superior strength and design
Engineered for optimal heat transfer to cylinder walls
Elliptical design to evenly distribute thrust loads and prevent piston collapse
Manufactured in Germany

Specifications

Bore: 67.01mm (actual size 66.95mm)
Part Number: 56-W642.00B.WO
Lock Part Number: CW18
Pin Part Number: WP033
Ring Set Part Number: RSB6700 x 2
Displacement: 246 cm³
Stroke: 70.80mm
Clearance: 0.06mm
Wossner Compression Ratio: 2-stroke
OEM Compression Ratio: 2-stroke
Compression Height: 37.00mm

Cross-Reference OEM Part Numbers

Piston: 12110-28C11-0F0, 12110-29E20-0F0
Ring, Piston: 12141-41600, 12141-41620
Pin, Piston: 12151-28C00, 12151-37F00
Circlip: 09381-18002

Vehicle Fitments

1993 Suzuki RM 250
1993 Suzuki RMX 250
1994 Suzuki RM 250
1994 Suzuki RMX 250
1995 Suzuki RM 250
1995 Suzuki RMX 250

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
SUZUKI	RMX 250	1989-1999
SUZUKI	RM 250	1989-1995

Piston Kit 89-95 RM250 67.00 B, Wossner 8022DB Suzuki MX

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

The Wossner 8022DB piston with a 67.01mm bore (66.95mm actual size) is engineered for high performance and durability, fitting Suzuki... Read more

Out of stock

£0.00 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W642.00B.WO

Free shipping on all orders above £75

No hassle returns within 30 days

Description

The Wossner 8022DB piston with a 67.01mm bore (66.95mm actual size) is engineered for high performance and durability, fitting Suzuki RM250 (1989-1995) and RMX250 (1993-1995) models. Forged in Germany, this piston is designed to optimise heat transfer from the combustion chamber to the cylinder walls. Its elliptical shape ensures uniform bearing surfaces during heat expansion, preventing localised pressure and piston collapse.

Features

Forged construction for superior strength and design
Engineered for optimal heat transfer to cylinder walls
Elliptical design to evenly distribute thrust loads and prevent piston collapse
Manufactured in Germany

Specifications

Bore: 67.01mm (actual size 66.95mm)
Part Number: 56-W642.00B.WO
Lock Part Number: CW18
Pin Part Number: WP033
Ring Set Part Number: RSB6700 x 2
Displacement: 246 cm³
Stroke: 70.80mm
Clearance: 0.06mm
Wossner Compression Ratio: 2-stroke
OEM Compression Ratio: 2-stroke
Compression Height: 37.00mm

Cross-Reference OEM Part Numbers

Piston: 12110-28C11-0F0, 12110-29E20-0F0
Ring, Piston: 12141-41600, 12141-41620
Pin, Piston: 12151-28C00, 12151-37F00
Circlip: 09381-18002

Vehicle Fitments

1993 Suzuki RM 250
1993 Suzuki RMX 250
1994 Suzuki RM 250
1994 Suzuki RMX 250
1995 Suzuki RM 250
1995 Suzuki RMX 250

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
SUZUKI	RMX 250	1989-1999
SUZUKI	RM 250	1989-1995
