Name: Piston Kit 91-94 KTM300 72.01, Wossner 8012DB Forged
Brand: Wossner
SKU: 56-W631.B.WO

Piston Kit 91-94 KTM300 72.01, Wossner 8012DB Forged

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

The Wossner 8012DA (+0.01) piston kit features a 72.01mm bore (actual 71.94mm) and is engineered for superior strength and effective heat transfer to cylinder walls. The forged, elliptically designed piston ensures a more uniform bearing surface during heat expansion, minimising localised pressure and evenly distributing thrust loads to prevent piston collapse. Manufactured in Germany, this kit includes the necessary components for a durable rebuild and is suitable for KTM 300 models from 1990 to 1994.

Features

Forged piston construction for superior strength and longevity
Optimised for efficient combustion chamber heat transfer
Elliptical design provides a uniform bearing surface under heat expansion
Minimises localised pressure and prevents piston collapse
Made in Germany

Specifications

Bore Size: 72.01mm (Actual 71.94mm)
Display (cm³): 297
Stroke (mm): 72.00
Clearance (mm): 0.07
Compression Ratio (Wossner 2-stroke): 2 stroke
Compression Ratio (OEM 2-stroke): 2 stroke
Compression Height (mm): 29.70

Cross-Reference OEM Part Numbers

Wossner Piston Kit Part No: 8012DA (+0.01)
Lock Part No: CW18
Pin Part No: WP039
Ring Set Part No: RSB7200

Vehicle Fitments

1990 KTM GS300
1990 KTM MX300
1990 KTM EXC300
1991 KTM GS300
1991 KTM MX300
1991 KTM EXC300
1992 KTM GS300
1992 KTM MX300
1992 KTM EXC300
1993 KTM GS300
1993 KTM MX300
1993 KTM EXC300
1994 KTM GS300
1994 KTM MX300
1994 KTM EXC300

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
KTM	MX 300	1990-1994
KTM	EXC 300	1990-1994
KTM	GS 300	1990-1994
KTM	EXC 300	1991-1994
KTM	MX 300	1991-1994
KTM	GS 300	1991-1994

Piston Kit 91-94 KTM300 72.01, Wossner 8012DB Forged

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

The Wossner 8012DA (+0.01) piston kit features a 72.01mm bore (actual 71.94mm) and is engineered for superior strength and effective... Read more

Out of stock

£0.00 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W631.B.WO

Free shipping on all orders above £75

No hassle returns within 30 days

Description

The Wossner 8012DA (+0.01) piston kit features a 72.01mm bore (actual 71.94mm) and is engineered for superior strength and effective heat transfer to cylinder walls. The forged, elliptically designed piston ensures a more uniform bearing surface during heat expansion, minimising localised pressure and evenly distributing thrust loads to prevent piston collapse. Manufactured in Germany, this kit includes the necessary components for a durable rebuild and is suitable for KTM 300 models from 1990 to 1994.

Features

Forged piston construction for superior strength and longevity
Optimised for efficient combustion chamber heat transfer
Elliptical design provides a uniform bearing surface under heat expansion
Minimises localised pressure and prevents piston collapse
Made in Germany

Specifications

Bore Size: 72.01mm (Actual 71.94mm)
Display (cm³): 297
Stroke (mm): 72.00
Clearance (mm): 0.07
Compression Ratio (Wossner 2-stroke): 2 stroke
Compression Ratio (OEM 2-stroke): 2 stroke
Compression Height (mm): 29.70

Cross-Reference OEM Part Numbers

Wossner Piston Kit Part No: 8012DA (+0.01)
Lock Part No: CW18
Pin Part No: WP039
Ring Set Part No: RSB7200

Vehicle Fitments

1990 KTM GS300
1990 KTM MX300
1990 KTM EXC300
1991 KTM GS300
1991 KTM MX300
1991 KTM EXC300
1992 KTM GS300
1992 KTM MX300
1992 KTM EXC300
1993 KTM GS300
1993 KTM MX300
1993 KTM EXC300
1994 KTM GS300
1994 KTM MX300
1994 KTM EXC300

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
KTM	MX 300	1990-1994
KTM	EXC 300	1990-1994
KTM	GS 300	1990-1994
KTM	EXC 300	1991-1994
KTM	MX 300	1991-1994
KTM	GS 300	1991-1994
