Name: Piston Kit A Grade 2002-2008 CRF450R 100 Forged Wossner 8546D400
Brand: Wossner
SKU: 56-W4820_400HC

Piston Kit A Grade 2002-2008 CRF450R 100 Forged Wossner 8546D400

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

Wossner 100.00mm high-compression big bore forged piston kit is designed for enhanced engine performance. Engineered for optimal heat transfer, it ensures efficient cooling of the combustion chamber. The elliptical design provides a uniform bearing surface, reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany for precision and reliability.

Features

High-compression and big bore design for increased performance
Forged construction for enhanced strength and longevity
Optimized heat transfer for efficient cooling
Elliptical design prevents piston collapse and ensures even load distribution
Manufactured in Germany for high-quality standards

Specifications

Bore Size: 100.00mm
Actual Bore Diameter: 99.96mm
Displacement: 449 cm³
Stroke: 62.10mm
Clearance: 0.04mm
Wossner Compression Ratio: 12.00:1
OEM Compression Ratio: 11.50:1
Dome Volume: -2.20 cm³
Compression Height: 24.00mm
Gasket Part Number: D4006
Lock Part Number: CW19
Pin Part Number: WP037
Ring Set Part Number: 1000AD-2
Rod Part Number: P4026

Cross-Reference OEM Part Numbers

Part No: 56-W4820_4.00HC
Wossner Part No: 8546D400

Vehicle Fitments

Honda CRF450R (2002 - 2003)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
HONDA	CRF R 450	2002-2006
HONDA	CRF X 450	2005-2016
HONDA	CRF R 450	2002-2008
HONDA	CRF R 450	2004
KAWASAKI	KLX 400	2003-2006
HONDA	CRF R 450	2007-2008
HONDA	CRM F R 450	2007
HONDA	CRE F R 450	2007

Piston Kit A Grade 2002-2008 CRF450R 100 Forged Wossner 8546D400

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

Wossner 100.00mm high-compression big bore forged piston kit is designed for enhanced engine performance. Engineered for optimal heat transfer, it... Read more

Out of stock

£0.00 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W4820_400HC

Free shipping on all orders above £75

No hassle returns within 30 days

Description

Wossner 100.00mm high-compression big bore forged piston kit is designed for enhanced engine performance. Engineered for optimal heat transfer, it ensures efficient cooling of the combustion chamber. The elliptical design provides a uniform bearing surface, reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany for precision and reliability.

Features

High-compression and big bore design for increased performance
Forged construction for enhanced strength and longevity
Optimized heat transfer for efficient cooling
Elliptical design prevents piston collapse and ensures even load distribution
Manufactured in Germany for high-quality standards

Specifications

Bore Size: 100.00mm
Actual Bore Diameter: 99.96mm
Displacement: 449 cm³
Stroke: 62.10mm
Clearance: 0.04mm
Wossner Compression Ratio: 12.00:1
OEM Compression Ratio: 11.50:1
Dome Volume: -2.20 cm³
Compression Height: 24.00mm
Gasket Part Number: D4006
Lock Part Number: CW19
Pin Part Number: WP037
Ring Set Part Number: 1000AD-2
Rod Part Number: P4026

Cross-Reference OEM Part Numbers

Part No: 56-W4820_4.00HC
Wossner Part No: 8546D400

Vehicle Fitments

Honda CRF450R (2002 - 2003)

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
HONDA	CRF R 450	2002-2006
HONDA	CRF X 450	2005-2016
HONDA	CRF R 450	2002-2008
HONDA	CRF R 450	2004
KAWASAKI	KLX 400	2003-2006
HONDA	CRF R 450	2007-2008
HONDA	CRM F R 450	2007
HONDA	CRE F R 450	2007
