Name: Piston Kit LTR450 Hc 95.50 B, Wossner 8699DB 13.3:1 Comp, Suzuki
Brand: Wossner
SKU: 56-W4912.WO.B

Piston Kit LTR450 Hc 95.50 B, Wossner 8699DB 13.3:1 Comp, Suzuki

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

The Wossner 8699DB forged piston kit is a high-compression piston with a 95.51mm bore, specifically designed for Suzuki LTR450 models from 2002 to 2011. This German-engineered piston improves heat management and durability through its forged construction and elliptical design, which distributes pressure evenly and prevents piston collapse during high-temperature operation.

Features

High-compression forged piston for increased strength and performance
Designed for optimal heat transfer from combustion chamber to cylinder walls
Elliptical design ensures uniform load distribution under heat expansion
Reduces risk of localized pressure and piston collapse
Manufactured in Germany

Specifications

Bore: 95.51 mm
Actual Bore Diameter: 95.46 mm
Display: 450 cm³
Hub Stroke: 62.80 mm
Clearance: 0.05 mm
Compression Height: 24.50 mm
Dome Volume: +2.30 cm³
Wossner Compression Ratio: 13.30:1
OEM Compression Ratio: 11.70:1

Cross-Reference OEM Part Numbers

Piston: 8699DB
Lock: CW19
Pin: WP037
Ring Set: 955XSY
Rod: P4011
Part No.: 56-W4912.WO.B

Vehicle Fitments

Suzuki LTR450 2002–2011

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
SUZUKI	LTR 450	2006-2009

Piston Kit LTR450 Hc 95.50 B, Wossner 8699DB 13.3:1 Comp, Suzuki

Wossner
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

The Wossner 8699DB forged piston kit is a high-compression piston with a 95.51mm bore, specifically designed for Suzuki LTR450 models... Read more

Out of stock

£0.00 Incl. VAT

Guaranteed secure & safe checkout.

SKU: 56-W4912.WO.B

Free shipping on all orders above £75

No hassle returns within 30 days

Description

The Wossner 8699DB forged piston kit is a high-compression piston with a 95.51mm bore, specifically designed for Suzuki LTR450 models from 2002 to 2011. This German-engineered piston improves heat management and durability through its forged construction and elliptical design, which distributes pressure evenly and prevents piston collapse during high-temperature operation.

Features

High-compression forged piston for increased strength and performance
Designed for optimal heat transfer from combustion chamber to cylinder walls
Elliptical design ensures uniform load distribution under heat expansion
Reduces risk of localized pressure and piston collapse
Manufactured in Germany

Specifications

Bore: 95.51 mm
Actual Bore Diameter: 95.46 mm
Display: 450 cm³
Hub Stroke: 62.80 mm
Clearance: 0.05 mm
Compression Height: 24.50 mm
Dome Volume: +2.30 cm³
Wossner Compression Ratio: 13.30:1
OEM Compression Ratio: 11.70:1

Cross-Reference OEM Part Numbers

Piston: 8699DB
Lock: CW19
Pin: WP037
Ring Set: 955XSY
Rod: P4011
Part No.: 56-W4912.WO.B

Vehicle Fitments

Suzuki LTR450 2002–2011

Vehicle Compatibility

Please check the exact model and year before ordering.

Manufacturer	Model	Years
SUZUKI	LTR 450	2006-2009
