Pit Bike Triple Clamp Set 45mm 48mm Forks

Description

This universal aluminium triple clamp set is designed for upside-down (USD) front forks on pit and dirt bikes. It provides secure fork clamping with 45 mm (upper) and 48 mm (lower) bores, making it suitable for CRF50-style and similar pit bike front ends.

Features

  • Complete triple clamp set
  • Designed for upside-down (USD) front forks
  • Aluminium construction

Specifications

  • Upper clamp bore diameter: 45 mm
  • Lower clamp bore diameter: 48 mm
  • Column (steering stem) length: ~~240 mm
  • Column (steering stem) width: 22/23mm
  • Bolt-to-bolt distance: 156 mm
  • Bearing sizes (tapered roller): 320/22 and 320/23

Vehicle Fitments

  • Universal fit for Chinese pit bikes using 45 mm/48 mm USD forks
  • Suitable for small, midsize, and big-wheel pit bike frames
  • Commonly used on CRF50-style frames and similar models

Does not include risers - spacing is roughly 35mm between holes and accepts up to M8 bolts

Pit Bike Triple Clamp Set 45mm 48mm Forks

Product form

This universal aluminium triple clamp set is designed for upside-down (USD) front forks on pit and dirt bikes. It provides... Read more

Out of stock

£34.00 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    SKU: 16-3532
    Barcode: 0120000071456

    • Free shipping on all orders above £75
    • No hassle returns within 30 days

    Description

    This universal aluminium triple clamp set is designed for upside-down (USD) front forks on pit and dirt bikes. It provides secure fork clamping with 45 mm (upper) and 48 mm (lower) bores, making it suitable for CRF50-style and similar pit bike front ends.

    Features

    • Complete triple clamp set
    • Designed for upside-down (USD) front forks
    • Aluminium construction

    Specifications

    • Upper clamp bore diameter: 45 mm
    • Lower clamp bore diameter: 48 mm
    • Column (steering stem) length: ~~240 mm
    • Column (steering stem) width: 22/23mm
    • Bolt-to-bolt distance: 156 mm
    • Bearing sizes (tapered roller): 320/22 and 320/23

    Vehicle Fitments

    • Universal fit for Chinese pit bikes using 45 mm/48 mm USD forks
    • Suitable for small, midsize, and big-wheel pit bike frames
    • Commonly used on CRF50-style frames and similar models

    Does not include risers - spacing is roughly 35mm between holes and accepts up to M8 bolts
